Plan A16
$995.00
Our 18' x 24' A16 Cabin may be compact, but it’s loaded with character. Whether you're dreaming of a weekend retreat or embracing the tiny home lifestyle full-time, this charming timber frame cabin delivers warmth, simplicity, and timeless style. The plan includes everything you need to get started building—from door and window schedules to timber and fastener lists.
We provide architectural elevations, frame elevations, all wall layouts, beam layouts, rafter layout, fastening details, and complete single beam drawings. The frame features 8x8 posts, 8x12 plate beams, 6x8 tie beams, 8x10 girders, 6x8 joists, 4x8 rafters, and 4x6 knee braces. With vaulted ceilings, a stone-accented entry, and a cozy sleeping loft, this cabin balances rustic beauty with thoughtful design.
Let us help you bring this quiet woodland escape to life today.
Frame Specifications:
- Size: 18' x 24'
- Joinery: Mortise and Tenon
- Posts: 8x8
- Plate Beams: 8x12
- Tie Beam: 6x8
- Girder: 8x10
- Joists: 6x8
- Rafters: 4x8
- Knee Braces: 4x6
- Roof: 12 Pitch, Dormer: 7 Pitch
- Wall Height: 12'-9 1/2"
- Rafter Overhang: 2'
This Plan Includes the Following:
Architectural Items:
*All Architectural Item Pages to be Printed on 24" x 36" Paper Size*
Elevations
Floor Plans
Door and Window Schedules
Electrical Plan
Foundation Plan
Roof Plan
Wall Section
Building Section
Stair Specifications (if applicable)
Timber Frame Items:
*All Timber Frame Item Pages to be Printed on 11" x 17" Paper Size*
- 3D Renderings
- Material List
- Wall/Post Layout
- Wall Layouts
- Joist Layout
- Rafter/Plate Layout
- Fastening Details
- Single Beam Drawings
Quantity
Timber Frame Kit Package
The CNC Pre-Cut Frame for this Cabin starts at $21,995. Contact us for more information.
Delivery
After checkout, you’ll receive a short form to provide your name, location, and basic project info. We’ll personalize your plan set and send it to you within 2–3 business days via email. Please save your file and print according to the page sizes noted on the drawings.
Building Disclaimer
The frame design shown has not been engineered and is only intended as a general outline. It is the sole responsibility of the homeowner and/or contractor to determine if local or state code requires an engineer’s stamp on plans before erection. Team Timber, LLC does not design to a specific area and for that matter will not hold any reasonability or warranty plans if plans do not satisfy the requirements of local and/or state building codes.
Copyright Policy
The buyer agrees that when purchasing a plan, they may only build one structure or building per plan bought. They cannot reproduce the plan or any part of it without written consent of Team Timber.
T-Rex Connector Conversion
Contact us to get more information and pricing on converting this plan to use T-Rex Connectors. To learn more about the connectors you can visit their website, https://ctpostandbeam.com.
