This 12' x 16' Shed would be great just about anywhere.  This full plan includes everything to get you started building your dream Shed.  We provide a sample foundation plan, sample first floor plan, sample architectural elevations with door and window schedules, a cross section detail, timber/fastener/connector list, all wall layouts, beam layouts, rafter layout, fastening details, and all single beam drawings.  It uses 6x6 posts, 6x8 plate beams, 6x8 tie beams, 4x6 joists, 4x5 knee braces, 6x8 ridge plates and 4x6 and 6x6 rafters. Let us help you get started today with this set of plans!


Building Specifications:

  • Size: 12' x 16'
  • Total Square Footage: 294


Frame Specifications:

*Timbers are 1/2" Under Full Dimension*

  • Joinery: Mortise and Tenon
  • Posts: 6x6
  • Plate Beams: 6x8
  • Tie Beams: 6x8
  • Joists: 4x6
  • Ridge Plates: 6x8
  • Knee Braces: 4x5
  • Rafters: 4x6 and 6x6
  • Roof: 12 Pitch
  • Wall Height: 7'-8"


This Plan Includes the Following:

*Note - These are considered Timber Frame Only Plans, contact us for adding additional items.*

Architectural Items:

*All Architectural Item Pages to be Printed on 24" x 36" Paper Size*

  • Sample Foundation Plan
  • Sample Architectural Elevations
  • Door and Window Schedules
  • Sample Floor Plan
  • Cross Section Detail
  • Timber Frame Overview


Timber Frame Items:

*Timber Frame Construction Document Pages and Single Beam Drawings to be Printed on 11" x 17" Paper Size*


  • 3D Renderings
  • Material List
  • Wall/Post Layout
  • Wall Layouts
  • Joist Layout
  • Rafter/Plate Layout
  • Fastening Details
  • Single Beam Drawings

12' x 16' Bridgewater Shed III

  • The CNC Pre-Cut Frame for this Shed starts at $7,495.  Contact us for more information.
